Howo concrete mixer intended to get the cement work done
Howo 7 Mixer Truck 6X4
| Cabin | Driving type 6×4 LHD/RHD T7H-W-Wide-body low-floor Lengthen Cab Flat roof.Option:Upgrade Edition;single bunk,safety belts, A/C, 70°hydraulically tillable to the front as attached photo for ref. |
||
| Dimensions | Overall dimensions (L×W×H)mm | 10005x2496x3980 | |
| Wheel base (mm) | 4025+1350 | ||
| Weight in KGS | Tare Weight | 14170 | |
| Loading Capacity | 12070 | ||
| Front axles loading capacity | 1×9000 | ||
| Rear axles loading capacity | 2×16000 | ||
| Performance | Maximum driving speed (km/h) | 80 | |
| Engine | Brand | SINOTRUK | |
| Type | 6-cylinder in line,4-stroke,water-cooled,supercharging intermediate cooler,high pressure common rail | ||
| Horse Power (HP)/(KPM) | 390HP | ||
| Emission standard | Euro III | ||
| Transmission | HW19710 or HW23710 transmission,10 forward and 2Â reverse | ||
| Steering Gear | ZF power steering, modol ZF8098, hydraulic steering with power assitance | ||
| Fuel tank (L) | 400 | ||
| Tire | 12.00-20,Optional 12.00R20,11.00-20,11.00R20 | ||
| Mixer Body | |||
| Volume | 12 CBM | ||
| Body Thickness | High tensile strength steel 6mm | ||
| Hydraulics | German or Italy made imported | ||
| German or Italy made imported | |||
| German or Italy made imported | |||
Performance
Howo dump truck is as versatile as your day to day challenges on the construction and mining site. Thanks to Sinotruk engine, it brings even more transport capacity and safety to your construction site. Making it a reliable and efficient partner for your work.
Safe and Reliable
More efficient and economical 2.0T turbocharger engine. McPherson independent front suspension / High-strength rear suspension with torsion beam Ultra-high-strength cage body, Reinforced boron
Comfortable driving
Bosch 9.3 ESP single tube hydraulic shock absorberFront and rear independent suspension
Exclusive luxury
Luxury interior upholstery in leather in contrasting colors, ergonomic seats. 10.25-inch waterfall high-definition large screen, intelligent car connection.
Gallery：
SINOTRUK Howo Concrete Mixer Truck makes hauling concrete, mixing it all the way up to the job site. The best Howo concrete mixer truck chassis and mixer system mean everything happens on top of a strong foundation.
